hth calcium hypochlorite feeder up to 1000 m³ Easiflo 20 Light, for pools (for hth BRIQUETTE), France

SKU	220549
Feeder dimensions	723x555x1173 mm
Tablet loading	20 kg
Pool	up to 1000 m³
Chlorine solution concentration at a pressure of 1 bar	1.2%
Protection against accidental opening of the feeder lid	Yes
Maximum active chlorine feed rate at 1 bar pressure	24 kg/day
Backwash system	Yes
Number of sprayers	2
Country of manufacture	France

The hth Easiflo 20 Light chlorine tablet/briquette feeder is an ideal water treatment system for pools with a volume of up to 1000 m3.

Purpose: for dosing dry inorganic chlorine in commercial and private swimming pools. The EASIFLO 20 feeder doses and regulates the supply of disinfectant solution to the pool. The chlorine feeder is installed last in the pool water filtration circuit to avoid damage to the equipment by chemicals. Since pool water is a favorable environment for the growth of various microorganisms, disinfectants must be added to the water and the pH level must be monitored. The feeder is charged by simply adding calcium hypochlorite briquettes without stabilizer. It consists of a tablet compartment, a tablet dissolving bowl and a drain reservoir.

The unit doses dry, inorganic and unstabilized chlorine.

Specifications: load weight 20 kg, for pools with a volume of up to 1000 m3. Can be used together with dosing pumps and automatic dosing stations. To create the required flow of water through the feeder, a pressure of 0.15-1.4 bar is required at the feeder's water intake point. Maximum active chlorine feed rate at a pressure of 1 bar - 24 kg/day
